ZD740 Ultrasonic Thickness Gauge
The ultrasonic thickness gauge are featured as cost-efficiency and designed to make accurate measurements on steel, cast iron, aluminum, red copper, zinc,
quartz glass, polyethylene, PVC, gray cast iron and nodular cast iron. Thickness measurements are made from one side of the material with no need to cut the part.
Features:
--Available for gauging various materials such as metal, glass, rubber and etc.
--Whole range transducer models are available for almost all kinds of application, including coarse grain material gauging and high temperature applications(Max.temperature up to 300℃)
-- Automatically recognizing for probes allowing the gauge to match with probes made from various probe’s manufactures.
--Power on automatic testing function contributing to measurement accuracy increasing.
--Auto power off detection and customizing power off configuration
--Probe Zero function, Sound Velocity Calibration function
--9 velocities built in and programmable
--7 practical measurement modes available: Standard Mode, Scanning Mode, Difference Mode, Average Mode, Maximum Limitation Alert Mode, High Temperature Mode(should be matched with high temperature probe)
--8 button keyboard designing for convenient shortcut operations for Probe-zero function, One-point and Two-point calibration, as well as numerical adjusting with direction key control.
--Large data storage capacity, Max. Up to 2000 groups. Every group can reach to 99 data.
--Metric-inch free convertible.
--USB data interface communication, easily accomplishing data transferring with PC and outputting data with “.txt.”
Product Specification:
Model | ZD740 |
Measurement Range | 0.65~400mm |
Material Velocity Range | 509~18699m/s |
Measuring Accuracy | ±(0.5%H+0.05)mm |
Display Accuracy | 0.01mm/0.001inch |
Scanning Rate | 2~20 times/sec |
Frequency Bandwidths | 1~10MHz |
Measuring lower limit of pipes | Φ15mm×1.0mm (Probe: 5MHz, Φ10mm) Φ10mm×1.2mm (Probe: 7.5MHz, Φ6mm) |
Display Mode | 128×64 matrix LED |
Power supply | 2 AA Alkaline Batteries |
Operating Time | 280 hours typical battery life, 100 hours continuous with backlight on |
Operating Temperature Range | -10℃~50℃(Ambient Environment) -10℃~300℃(High Temperature Mode) |
USB | |
Gauge Size | 136 mm×72 mm×20mm |
Weight | 176g(Including Batteries) |
Configuration:
No. | Item | Quantity | Note | |
Standard Configuration | 1 | Main body | 1 | |
2 | Transducer | 1 | 5MHz, Φ10mm | |
3 | Couplant | 1 | 30ml, Glycerin | |
4 | Instrument Case | 1 | ||
5 | Operating Manual | 1 | ||
6 | Alkaline battery | 2 | AA size | |
7 | USB Cable | 1 | ||
8 | Software Disk | 1 | ||
Optional Configuration | 9 | Wide-range transducer:2.5MHz, Φ12mm | 3~400mm(-10~50℃) | |
10 | High-precision transducer:7.5MHz, Φ10mm | 0.65~100mm(-10~50℃) | ||
11 | Micro-diameter transducer:7.5MHz, Φ6mm | 0.75~60mm(-10~50℃) | ||
12 | Cast iron transducer:2MHz, Φ12mmor Φ22mm | 3~50mm(-10~50℃) | ||
13 | High temperature transducer:5MHz, Φ12mm | 4~80mm(-10~350℃) |
